• T6  Integrated  Stereo  Amplifier





     Specifications:

    Input  Impedance: >30KΩ
    Sensitivity(same at all terminal): 300mVrms
    Output  Power:(THD≤1%) 2×100W(1KHz,8Ω),

    2×150W(1KHz,4Ω)

    Signal to Noise Ratio: ≥100dB(A-weighted
    THD+Noise: ≤0.08%(1KHz,90W,8Ω)

    Headphone/Earphone terminal

    (Φ6.35mm plug)

    Maximum  Output  Level:

    ≥6Vrms/600Ω

    Impedance for Headphones 60~600Ω
    Dimensions: 434(W)×105(H)×358(D) mm

    17(W)×4.13(H)×14(D)  in

    Shipping Weight 13.5  kg

    29.7  lb
